PID controller in the SK 300E
Ramp setpoint
P416
Maximum frequency P105
Minimum frequency P104
Maximum frequency
auxiliary setpoint P410
Minimum frequency
auxiliary setpoint P411
Analog input 1
Analog input 2
Bus setpoint 3
Bus setpoint 2
Auxiliary
setpoint sources
PotentiometerBox
P400-P404
Scaling
P405-P409
Scaling
Analog input 1
Analog input 2
Bus setpoint 1,2,3
Main
setpoint sources
Fixed frequency 1-5
ControlBox /
PotentiometerBox
Jog frequency
P400-P404
Scaling
P405-P409
Scaling
Also in combination,
see setpoint
adjustment
