7.11 Parameter overview, User settings
BU 0300 EN
Subject to technical alterations
115
7.11
Parameter overview, User settings
(P)
⇒ Parameter set dependent, these parameters can be differently adjusted in 4 parameter sets.
S
⇒ Supervisor parameter, visibility depends on P003.
Parameter
No.
Name
Factory
setting
Super-
visor
Setting after commissioning
P 1
P 2
OPERATING DISPLAYS (6.4)
P001 Selection
display
0
P003 Supervisor
code
0
0= S parameters are hidden
1= all parameters are visible
BASIC PARAMETERS (6.5)
P100 Parameter
set
0
S
P101
Copy parameter set
0
S
P102
(P) Acceleration time [s]
2.0
P103
(P) Deceleration time [s]
2.0
P104
(P) Minimum frequency [Hz]
0.0
P105
(P) Maximum frequency [Hz]
50.0
P106
(P) Ramp smoothing [%]
0
S
P107
(P) Brake reaction time [s]
0.00
P108 (P)
Disconnection
mode
1
S
P109
(P) DC brake current [%]
100
S
P110
(P) DC braking time on [s]
2.0
S
P112
(P) Torque current limit [%]
401 (off)
S
P113 (P)
Jog
frequency
[Hz]
0.0
S
MOTOR DATA / CHARACTERISTIC CURVE PARAMETERS (6.6)
P200 (P)
Motor
list
0
S
P201
(P) Nominal frequency [Hz]
50.0 *
S
P202
(P) Nominal speed [rpm]
1385 *
S
P203
(P) Nominal current [A]
4.8 *
S
P204
(P) Nominal voltage [V]
230 *
S
P205
(P) Nominal power [kW]
1.10 *
S
P206 (P)
Cos
phi
0.78 *
S
P207
(P) Motor circuit [star=0/delta=1]
1 *
S
P208
(P) Stator resistance [Ω]
6.28*
S
P209
(P) No load current [A]
3.0 *
S
P210
(P) Static boost [%]
100
S
P211 (P)
Dynamic
boost
[%]
100
S
P212
(P) Slip compensation [%]
100
S
P213
(P) ISD control loop gain [%]
100
S
P214
(P) Torque precontrol [%]
0
S
P215
(P) Boost precontrol [%]
0
S
P216
(P) Time boost precontrol [s]
0.0
S
*) dependent on FI power or P200/P220
