9
B
ASIC
O
PERATION
Many Management Functions, such as Close, Journal, and Diagnostic functions, produce a report summa-
rizing the results of the operation. Most reports are displayed in a Management Report dialog, which you
can use to print the report to the receipt printer or save to an external memory device (USB jumpdrive).
The buttons on the Management Report dialog let you perform the following actions:
1. P
AGE
U
P
. Scrolls the report up a maximum of
one full page.
2. H OME . Moves directly to the first page of the
report.
3. P RINT . Sends the report to the terminal receipt
printer for hardcopy output.
4. P
AGE
D
OWN
. Scrolls the report down a maxi-
mum one full page.
5. E ND . Moves directly to the last page of the
report.
6. S AVE TO F ILE . Saves the report as a text file to
an external memory device.
M
ANAGEMENT
R
EPORTS
Note: If saving to an external memory device, the device must be installed (USB port) BEFORE saving
to that device.
The following parameters minimally need to be configured to enable a “live” transaction:
P IN W ORKING K EY
C ASSETTE P ARAMETERS
T ERMINAL ID N UMBER
C OMMUNICATION P ROPERTIES
P
IN
M
ASTER
K
EY
R
EQUIRED
P
ARAMETERS
These parameters do not take in to account any additional processor requirements. Refer to the processor’s
setup requirements for any additional parameter settings .
Note: Upon completion of the ATM installation and terminal configuration, recommend accessing the
D
IAGNOSTICS
menu to check the status and test various hardware items (Dispenser, Printer, Card Reader,
etc).
