Chapter 11
Analog Inputs / 5 Volt Excitation
XL™ Series
Analog Inputs / 5 Volt Excitation. 11-1
11.1 Analog Inputs Overview
The four generic analog input channels are configured as single ended inputs with a default range
of 0.0 to 5.0 volts. A 5.00 volt switched excitation is also provided for sensors that require a
precision power reference. The analog setup screens allow the user to make simple conversions
from voltage to the desired units by defining a slope and offset for the analog input. The voltage
from the input is multiplied by the slope value and added to the offset value to produce the final
value.
11.2 Analog Menus
Built in Menu Structure: Analog Input Options.
Sensor Input Setup-> Analog 1 Setup -> Analog 1 = X.XXXX
Offset [0.0000 ]
Slope [1.0000 ]
A1 Samples [ 500]
Range [5.0 V ]
Differential Md [Off]
Note: Menu screens for analog channels 2, 3 and 4 are the same as shown above for analog
channel 1, except the ‘Differential Mode’ option is only available for channel 1 and 2.
PC Menu Screen: Analog Input Options.
Analog Input Setup (Esc to Return)
Analog 1: 0.1916 Analog 2: 0.1908 Analog 3: 0.1953 Analog 4: 0.1889
A - Slope: 1.000 E - Slope: 1.000 I - Slope: 1.000 M - Slope: 1.000
B - Offset: 0.000 F - Offset: 0.000 J - Offset: 0.000 N - Offset: 0.000
C - Samples:500 G - Samples:500 K - Samples:500 O - Samples:500
D - Range: 5.0 V H - Range: 5.0 V L - Range: 5.0 V P - Range: 5.0 V
X - Diff Mode: Off
Enter Option >
Note: Options and status information for all four analog channels is displayed on a single screen.
