A-2 Appendix A Specifications
XL™ Series
Miscellaneous Performance
Data Storage (All Units)
Type:
Non-Volatile ATA Compact FLASH Card
Size:
4 Mega Byte Minimum (Expandable)
SDI-12 Interface (All Units)
Mode
Supports Master and Slave modes
Protocol:
SDI-12, 7-bit even parity, 1 stop bit
Baud Rate:
1200
RS-232 Interface (All Units)
Number of Ports:
3 RS-232 External Communication Ports
1 RS-232 Internal Port.
Protocol:
RS-232, 8-bit, no parity, 1 stop bit
Baud Rate:
Programmable
Function:
Programable for each external port
Power (All Unts)
Input Voltage:
10.0 to 16.0 volts DC
Auto shut-off
Programmable
Power (H-350XL Only)
Input Current: Sleep Mode: 10 mA typical
Active:
70 mA average (display off)
250 mA average (display on)
Power (H-500XL / H-510XL)
Input Current: Sleep Mode: 5 mA Max
Active:
70 mA average (display off)
250 mA average (display on)
Power (H-522 Plus)
Input Current: Sleep Mode: 15 mA Max (GPS Off)
45 mA Max (GPS On)
Active:
70 mA average (display off)
250 mA average (display on)
Power (H-522)
Input Current: Sleep Mode: 15 mA Max (GPS Off)
45 mA Max (GPS On)
Active:
70 mA average
Warranty
The W
ATER
LOG XL™ is warranted against defects in materials
®
and workmanship for one year from date of shipment.
Mechanical Data
Physical (H-350XL Only)
Enclosure:
Sealed, corrosion resistant fiberglass with clear
Lexan window
®
Size:
7.0 in. wide x 8.5 in. long x 4.3 in. deep
Weight:
4.25 lbs
Mounting:
Hardware supplied for wall mounting
Physical (H-500XL / H-522)
Enclosure:
Sealed, corrosion resistant fiberglass with
clear Lexan window
®
Size:
7.0 in. wide x 8.5 in. long x 4.3 in. deep
Weight:
4.25 lbs (H-500XL)
7.50 lbs. (H-522)
Mounting:
Hardware supplied for wall mounting
Physical (H-510XL / H522 Plus)
Enclosure:
Sealed, corrosion resistant fiberglass with
clear Lexan window
®
Size:
8.0 in. wide x 10.0 in. long x 6.0 in. deep
Weight:
14.0 lbs
Mounting:
Hardware supplied for wall mounting
Environmental (All Units)
Temperature: Extended Operating Range:
-40 to 60°C
Storage:
-40 to 80°C
Humidity
0-95% non-condensing
Options And Accessories
Options
GOES:
H-222SE (Signal Engineering Radio)
H-222DA (Microcom Radio)
H-222DASE (Signal Engineering Radio)
Note: The H522/H522+ model has integrated GOES radio.
Accessories
Cables:
- Power/SDI-12 cable supplied with base unit
- 9-pin D connector cable required for RS-232
communication available (H-350-RSC)
- 9-pin D Male to Male Gender Changer
- RS-232 Null Modem Adaptor
- Sensor Terminal Block
Note: Specifications subject to change without prior notice due to
ongoing commitment to product testing and improvement.
