16-16 Operation with the GOES Radio
XL™ Series
Menus for Data Format set to SHEF:
Built in Menu Structure: GOES Self Timed Data Options, (SHEF Format).
(The menu shows some options set based on using an H-350XL™ with the built in stage sensor)
ST Data Options-> Source 1 [Stage]-> Source 2 [Temp ]-> ... Source 20 [None ]->
SHEF Code 1 [HG]-> SHEF Code 2 [TA]-> ... SHEF Code 20 [ ]->
MeasRate 1[HH:MM:SS] MeasRate 2[HH:MM:SS] ... MeasRate 20[HH:MM:SS]
Format 1 [XX.XX ] Format 2 [XX.XX ] ... Format 20[XX.XX ]
PC Menu Screen: GOES Self Timed Transmit Options, (SHEF Format).
(The menu shows some options set based on using an H-350XL™ with the built in stage sensor)
ST Transmit Options (SHEF or ASCII Mode) (Esc to Return)
A - All Meas. Rates Set To Scan Rate
Scan Rate = 00:05:00
Column | [01] 02 03 04 05
---------------|------------------------------------------------------------
S - Source: | Stage Temp None None None
C - SHEF Code: | HG TA
R - Meas Rate: | 00:15:00 00:15:00 00:15:00 00:15:00 00:15:00
F - Format: | XX.XX XX.XX XX.XX XX.XX XX.XX
-> - Next
<- - Previous
Enter Option >
PC Interface View Built In Display Screen
S - Source Source 1 [None ]
The source option is used to select what data value will be transmitted and in what order. Each
column normally has a different data source based on the standard input options. If the column
source option is set to “None” then that column and all following columns are disabled. When
this option is selected use the UP and DOWN arrow keys to view the valid options as listed
below.
None The column is turned off, and all following columns are ignored.
Date Place the date in the column (Normally the date is not sent as GOES data).
Time Place time in the column, (Normally the time is not sent as GOES data).
PSI Place the PSI reading in the column. (H-350XL™ model only)
