Chapter 6
Serial Port Options
XL™ Series
Serial Port Options 6-1
6.1 Introduction
The serial port setup options are found under the the “System Setup” or System Configuration”
menu. Since the options for the serial ports are an integral part of the operation of the unit they
will be discussed in their own chapter.
6.2 Serial Port Menus
Built in menu structure: Serial Port Options Menu
System Setup -> Serial Port Setup -> BaudRate Com1 [9600]
BaudRate Com2 [9600]
BaudRate Com3 [9600]
StartUp 1 [Menu Mode]
StartUp 2 [Menu Mode]
StartUp 3 [Menu Mode]
Flow Control [XXX]
Char Delay [XXX]
Line Delay [XXX]
Emulation [XXXXXX]
Quiet Mode [Off]
QuietModeDur[XXX]
