10-6 Built In Stage / Remote Stage Setup
XL™ Series
PC Interface View Built In Display Screen
1 - Remote Stage Source: None RemStage Src [None ]
This shows the current input source used for the remote stage and allows the user to change to a
different input source. Normally the input source is one of the SDI-12 inputs but can be any of
the other inputs also such as ANA1.
PC Interface View Built In Display Screen
2 - Remote Stage Offset: 0.000 Rem Offset [0.000 ]
This option screen allows the user to enter an offset value to adjust the final remote stage value in
order to obtain a stage value relative to some reference point such as sea level. The default offset
value of 0.000 can be manually changed by the user or automatically calculated by the XL as
discussed in the ‘Rem Stage’ section above. This offset value is stored in the XL, not in the
sensor.
PC Interface View Built In Display Screen
3 - Remote Stage Slope: 1.000 Rem Slope [1.000 ]
This option screen allows the user to enter a slope (multiplier) value that will be applied to the
remote stage measurement in order to convert the value into desired units. This the first term in
the equation: Value = Measured data * Slope + Offset. The default value is 1.00. This value is
stored in the XL, not in the sensor.
PC Interface View Built In Display Screen
M - Measure Not Available In Built In Menu
When using the PC menu, pressing the M key will cause the XL to take a measurement of the
internal stage and temperature sensors and the sensor used for the remote stage, then update the
screen with the new values.
