16-22 Operation with the GOES Radio
XL™ Series
DATA FORMAT / RANGE TABLE
Signed Values = N Signed Values = Y Resolution
Bytes Digits Min Max Min Max
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
0
0
0
0
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
0
0
0
0
0.0
0.0
0.0
0.0
0.00
0.00
0.00
0.00
0.000
0.000
0.000
0.000
0.0000
0.0000
0.0000
0.0000
63
4095
262143
16777215
6.3
409.5
26214.3
1677721.5
0.63
40.95
2621.43
167772.15
0.063
4.095
262.143
16777.215
0.0063
0.4095
26.2143
1677.7215
-32
-2048
-131072
-8388608
-3.2
-204.8
-13107.2
-838860.8
-0.32
-20.48
-1310.72
-83886.08
-0.032
-2.048
-131.072
-8388.608
-0.0032
-0.2048
-13.1072
-838.8608
31
2047
131071
8388607
3.1
204.7
13107.1
838860.7
0.31
20.47
1310.71
83886.07
0.031
2.047
131.071
8388.607
0.0031
0.2047
13.1071
838.8607
1
1
1
1
0.1
0.1
0.1
0.1
0.01
0.01
0.01
0.01
0.001
0.001
0.001
0.001
0.0001
0.0001
0.0001
0.0001
NOTE: The bold values show the default settings and range. If in question on how to set
this just use the default values. Changing these options can greatly affect how the
data must be decoded.
