19-2 Alarm Call Out

XL™ Series

PC Menu Screens: Alarm Call Out Options.

Alarm Call Out Options (Esc to Return)

A - Alarms Enabled: No
N - Number of Retries:0

Column | [1] 2 3 4 5
--------------------|---------------------------------------------------------
S - Source: | None None None None None
M - Trigger Mode: | > Set Pt > Set Pt > Set Pt > Set Pt > Set Pt
T - Trigger Point: | 1.000 1.000 1.000 1.000 1.000
R - Reset Point: | 0.000 0.000 0.000 0.000 0.000
I - ID Tag: | Al1 Al2 Al3 Al4 Al5
B - Site Number: | 0 0 0 0 0
C - Connection: | Direct Direct Direct Direct Direct
P - Phone#/Address: | N/A N/A N/A N/A N/A
Active / Tries: | No / 0 No / 0 No / 0 No / 0 No / 0

F - Force Transmission
-> - Next
<- - Previous

Enter Option >

PC Interface View Built In Display Screen

A - Alarms Enabled: No

Alarms Enabled [No ]

This option is used to enable or disable Alarm operations. The default is “No”.

PC Interface View Built In Display Screen

N - Number of Retries: 0

Alarm Retries [0]

In some cases there may be problems in sending the data. For example, if the user is using a radio
option which may have problems communicating based on a crowded network or environmental
conditions, etc then the user may desire to send the data a few times.

PC Interface View Built In Display Screen

S - Source

Source 1 [None ]->

This option is used to define what data will be sent. The data value for this source is also used to
test against the set point based on the trigger mode to see if the data should be sent.
