XL™ Series
Operation with the GOES Radio 16-17
Stage Place the stage reading in the column. (H-350XL™ model only)
PtTemp Place pressure transducer temperature reading in the column. (H-350XL™ only)
StgStd Place Standard Deviation value in the column. (H-350XL™ NOAA mode only)
StgOlr Place the number of outliers in the column. (H-350XL™ NOAA mode only)
RemStg Place the remote stage measurement reading in the column.
Counts Place the counts reading in the column.
TotCnt Place the total count reading in the column.
CtRate Place the count rate reading in the column.
Batt Place the battery reading in the column.
Ana1 to Ana4 Place analog X reading in the column.
Dig1 to Dig2 Evaluate digital I/O x and place a 0 or 1 in the column based to the results.
Freq
Place the converted frequency reading in the column.
Encodr Place the quadrature encoder count in the column.
Tscans Place the number of scans reading in the column.
Basic1 to Basic5 Place the value returned to the BasicX variable in the column.
SDI01 to SDI99 Place the selected SDI-12 reading in the column.
Fnt01 to Fnt40 Place the results of function xx in the column.
Note: The SDI-12 entries go from address 0 to 9. The parameter is always 1 to 9. The entry SDI
62 would indicate the sensor at address 6 and use the 2 parameter. nd
PC Interface View Built In Display Screen
C - SHEF Code SHEF Code 1 [XX]
The SHEF code for each data value may be defined by the user. This is normally a two character
entry that represents the data value. For example “HG” equals height gage, and “TA” equals
temperature ambient.
SHEF stands for ‘Standard Hydrometeorological Exchange Format’ (SHEF). This is a
documented set of rules for coding of data in a form for both visual and computer recognition. It
is designed specifically for real-time use and is not designed for historical or archival data
transfer. All the critical elements for identification of data are covered. Station identifiers,
parameter descriptors, time encoding conventions, unit and scale conventions, and comment
fields are all part of the code. The true SHEF implementation does not lend itself well to GOES
transmissions but using portions of it can be helpful.
PC Interface View Built In Display Screen
R - Meas Rate MeasRate [00:15:00]
This option is used to indicate how often the sensor for this column should be measured. Fifteen
