Chapter 15
Logging Options
XL™ Series
Logging Options 15-1
15.1 Logging Overview
The logging options are used to determine if and how the data will be stored to the internal
memory of the XL™. The following shows the “Logging Options” screen.
15.2 Logging Options Menus
The following menu structures represent the sub menus under the “Logging Options” header.
This is where the user defines which data will be stored in the data memory and other logging
functions.
Built in Menu Structure: Logging Options Menu.
Output Options -> Logging Options -> Logging [On ]
.NEW File [None]
Data Fmt [Normal]
Wrap Mode [Disabled]
Report Options -> Source 1 [Date ]->
Header 1[ ]->
Log Rate[HH:MM:SS]->
Digits 1 [2] ->
Col 1 Fn()[NOW ]->
Stat Scrn 1 [No ] ->
Notice the options in the far right column have arrows ‘->’ indicating there are more options to
the right. In this case this is the first column of a table and it will extend to the right for a total of
25 columns. As described in chapter 3, use the arrow keys to move around the table and other
editing techniques to make any desired changes in the table.
