16-26 Operation with the GOES Radio
XL™ Series
greater than 0.05. Another example would be; “(ana1>10.0) | (counts > 0.05)”. In this example
the value for analog channel 1 must be greater than 10.0 OR the counts input (normally rain fall)
must be greater than 0.05 in order for the function to be true, which would cause a random
transmission. The conditional statement can be edited using the local display / keypad or by
using the PC menu interface. See chapter 22 ‘Functions’ for a complete understanding on how to
enter, edit and evaluate the math and logic functions.
PC Interface View Built In Display Screen
T - Transmit Options RR Data Options ->
The submenus under this option allow the user to select the data to be sent to the radio and the
order. Defining the options here is like defining columns in a spreadsheet. Source #1 will be the
first data value sent to the GOES Radio, Source #2 the next and so on. Options include Date,
Time, Stage, PSI, Temp Battery Voltage, or any other input option. There are a total of five
screens for entering different sources under this option allowing up to five data values to be
transmitted randomly.
Built in Menu Structure: GOES Random Transmit Options.
GOES Options -
> Random Options -> RR Data Opts -> Source 1 [XXXXXX]
:
Source 5 [XXXXXX]
PC Menu Screen: GOES Random Transmit Options.
RR Transmit Options (Esc to Return)
Column: | [01] 02 03 04 05
---------------|-----------------------------------------------------------
-
S - Source: | None None None None None
-> - Next
<- - Previous
Enter Option >
