Chapter 10
Built In Stage / Remote Stage Setup
XL™ Series
Built In Stage / Remote Stage Setup 10-1
10.1 Stage Sensor and Remote Stage Overview
This chapter is divided into two main sections. The first section is for the built in pressure sensor
used to measure a stage value and internal temperature value. This option is only available on
the H-350XL.
The second section is for the remote stage setup. This option is in all XL series products.
10.2 Stage / Temperature Menus
Built in Menu Structure: Stage Options Menu. (H-350XL™ and H-510XL Models Only)
Sensor Input Setup-> Stage Setup -> Stage [X.XXX ]
Offset [0.000 ]
Stage Units[Feet ]
Averaging Time [001]
Datum [0.000]
PC Menu screen: Stage / Temperature Options. (H-350XL™ and H-510XL Models Only)
Remote Stage Options. (All XL Series Products)
Stage, Temperature Setup (Esc to Return)
S - Stage: 0.29
O - Offset: 0.00
U - Units: Feet
A - Averaging Time: 1 Seconds
Temperature: 24.02
T - Temp Units: Deg C
R - Remote Stage: 00.00
1 - Source: XXXXXX
2 - Offset: 0.000
3 - Slope: 0.000
M - Measure
Enter Option >
