XL™ Series
Operation with the GOES Radio 16-27
PC Interface View Built In Display Screen
S - Source Source 1 [None ]
The source option is used to select what data value will be transmitted and in what order. Each
column normally has a different data source based on the standard input options. If the column
source option is set to “None” then that column and all following columns are disabled. When
this option is selected use the UP and DOWN arrow keys to view the valid options. This is just
like setting up the data sources for the timed transmissions.
PC Interface View Built In Display Screen
Buffer Byte Count RR Buffer Cnt = 0
This is a status screen that shows how many bytes are in the random transmit buffer of the radio.
PC Interface View Built In Display Screen
F - Force Random transmission Transmit RR Data?
This option causes the system to immediately send the data defined in the Random Data Options
menu. This may be useful for testing the system. The radio will not send data if a transmission
has happened within the last minute as there must be a 1 minute delay between transmissions.
