XL™ Series
SDI-12 Operations 14-7
PC Menu Screen: SDI-12 Logger Mode Options.
SDI-12 Logger Mode Setup (Esc to Return / ? For Help)
T - No Response Timeout Value: 0.000
R - Reset to SDI-12 Logger Mode Defaults
V - View Current SDI-12 Values
a M - Adrs (a) Measurement Type
a P - Adrs (a) Serial Port
a A - Adrs (a) Redirect Option
SDI-12 Measure Port Address
Address Type Redirected
----------------------------------------------------------
0 - M SDI-12 0 Ok
1 - M SDI-12 1 Ok
2 - M SDI-12 2 Ok
3 - M SDI-12 3 Ok
4 - M SDI-12 4 Ok
5 - M SDI-12 5 Ok
6 - M SDI-12 6 Ok
7 - M SDI-12 7 Ok
8 - M SDI-12 8 Ok
9 - M SDI-12 9 Ok
Enter Option >
PC Interface View Built In Display Screen
T - No Response Timeout Value: 0.000 Timeout Val [0.000]
This will be the value used by the XL™ if an SDI-12 sensor does not respond. The default value
is 0.00 but this is sometimes valid data and makes it hard to see if the sensor is operating or not.
The user may select a number that is outside the normal range like -999 for a temperature sensor,
and now if the recorded value is -999 it is obvious the sensor did not respond.
PC Interface View Built In Display Screen
R - Reset to SDI-12 Logger Mode Defaults Not Available In Built In Menu
This option resets all the settings on this screen to the factory default value.
PC Interface View Built In Display Screen
V - View Current SDI-12 Values Not Available In Built In Menu
View the values for each address and parameter.
