XL™ Series
Operation with the GOES Radio 16-19
Menus for Data Format set to BINARY:
Built in Menu Structure: GOES Self Timed Data Options, (Binary Format).
(The menu shows some options set based on using an H-350XL™ with the built in stage sensor)
ST Data Options-> Source 1 [Stage]-> Source 2 [Temp ]-> ... Source 20 [None ]
MeasRate 1[HH:MM:SS] MeasRate 2[HH:MM:SS] ... MeasRate 20[HH:MM:SS]
No. Bytes 1 [3] -> No. Bytes 2 [3] -> ... No. Bytes 20 [3]
No. Digits 1 [2] -> No. Digits 2 [2] -> ... No. Digits 20 [2]
Sign [Signed Mag.]-> Sign [Signed Mag.]-> ... Sign [Signed Mag.]->
Column 1 Range: xxx Column 1 Range: xxx ... Column 1 Range: xxx
PC Menu Screen: GOES Self Timed Transmit Options, (Binary Format).
(The menu shows some options set based on using an H-350XL™ with the built in stage sensor)
ST Transmit Options (SHEF or ASCII Mode) (Esc to Return)
A - All Meas. Rates Set To Scan Rate
Scan Rate = 00:05:00
Column | [01] 02 03 04 05
---------------|------------------------------------------------------------
S - Source: | Stage Temp None None None
R - Meas Rate: | 00:15:00 00:15:00 00:15:00 00:15:00 00:15:00
B - Bytes | 3 3 3 3 3
D - Digits | 2 2 2 2 2
P - Sign Mode | Signed Mag. Signed Mag. Signed Mag. Signed Mag. Signed Mag.
Min Range | -1310.72 -1310.72 -1310.72 -1310.72 -1310.72
Max Range | 1310.72 1310.72 1310.72 1310.72 1310.72
-> - Next
<- - Previous
Enter Option >
PC Interface View Built In Display Screen
S - Source Source 1 [None ]
The source option is used to select what data value will be transmitted and in what order. Each
column normally has a different data source based on the standard input options. If the column
source option is set to “None” then that column and all following columns are disabled. When
this option is selected use the UP and DOWN arrow keys to view the valid options. See the
corresponding option under the ‘SHEF Mode’ transmit options above for more details
