DS31256

38 of 181

Bit 14/Status Bit for Local Bus Error (LBE). This status bit applies to the local bus when it is operated in PCI
bridge mode. It is set to 1 when the local bus LRDY signal is not detected within nine LCLK periods. This
indicates to the host that an aborted local bus access has occurred. If enabled through the LBE bit in the interrupt
mask for SM (ISM), the setting of this bit causes a hardware interrupt at the PCI bus through the PINTA signal pin
and also at the LINT if the local bus is in configuration mode. The LBE bit is meaningless when the local bus is
operated in the configuration mode and should be ignored.

Bit 15/Status Bit for Local Bus Interrupt (LBINT). This status bit is set to 1 if the local bus LINT signal has
been detected as asserted. This status bit is only valid when the local bus is operated in PCI bridge mode. The
LBINT bit is cleared when read and is not set again until the LINT signal pin once again has been detected as
asserted. If enabled through the LBINT bit in the interrupt mask for SM (ISM), the setting of this bit causes a
hardware interrupt at the PCI bus through the PINTA signal pin. The LBINT bit is meaningless when the local bus
is operated in the configuration mode and should be ignored.

Register Name:

ISM

Register Description: Interrupt Mask Register for SM
Register Address:

0024h

Bit

# 7 6 5 4 3 2 1 0

Name n/a n/a

n/a

PPERR PSERR SBERT STCOFA

SRCOFA

Default

0 0 0 0 0 0 0 0

Bit

# 15 14 13 12 11 10 9 8

Name LBINT

LBE n/a

n/a

n/a

n/a

n/a

n/a

Default

0 0 0 0 0 0 0 0

Note: Bits that are underlined are read-only; all other bits are read-write.


Bit 0/Status Bit for Receive Change-of-Frame Alignment (SRCOFA)

0 = interrupt masked

1 = interrupt unmasked


Bit 1/Status Bit for Transmit Change-of-Frame Alignment (STCOFA)

0 = interrupt masked

1 = interrupt unmasked

Bit 2/Status Bit for Change of State in BERT (SBERT)

0 = interrupt masked

1 = interrupt unmasked


Bit 3/Status Bit for PCI System Error (PSERR)

0 = interrupt masked

1 = interrupt unmasked

Bit 4/Status Bit for PCI System Error (PPERR)

0 = interrupt masked

1 = interrupt unmasked


Bit 14/Status Bit for Local Bus Error (LBE)

0 = interrupt masked

1 = interrupt unmasked


Bit 15/Status Bit for Local Bus Interrupt (LBINT)

0 = interrupt masked

1 = interrupt unmasked
