DS31256
27 of 181
4.3 Receive Port Registers (1xx)
OFFSET/
ADDRESS
NAME REGISTER SECTION
0100 RP0CR Receive Port 0 Control Register 6.2
0104 RP1CR Receive Port 1 Control Register 6.2
0108 RP2CR Receive Port 2 Control Register 6.2
010C RP3CR Receive Port 3 Control Register 6.2
0110 RP4CR Receive Port 4 Control Register 6.2
0114 RP5CR Receive Port 5 Control Register 6.2
0118 RP6CR Receive Port 6 Control Register 6.2
011C RP7CR Receive Port 7 Control Register 6.2
0120 RP8CR Receive Port 8 Control Register 6.2
0124 RP9CR Receive Port 9 Control Register 6.2
0128 RP10CR Receive Port 10 Control Register 6.2
012C RP11CR Receive Port 11 Control Register 6.2
0130 RP12CR Receive Port 12 Control Register 6.2
0134 RP13CR Receive Port 13 Control Register 6.2
0138 RP14CR Receive Port 14 Control Register 6.2
013C RP15CR Receive Port 15 Control Register 6.2
4.4 Transmit Port Registers (2xx)
OFFSET/
ADDRESS
NAME REGISTER SECTION
0200 TP0CR Transmit Port 0 Control Register 6.2
0204 TP1CR Transmit Port 1 Control Register 6.2
0208 TP2CR Transmit Port 2 Control Register 6.2
020C TP3CR Transmit Port 3 Control Register 6.2
0210 TP4CR Transmit Port 4 Control Register 6.2
0214 TP5CR Transmit Port 5 Control Register 6.2
0218 TP6CR Transmit Port 6 Control Register 6.2
021C TP7CR Transmit Port 7 Control Register 6.2
0220 TP8CR Transmit Port 8 Control Register 6.2
0224 TP9CR Transmit Port 9 Control Register 6.2
0228 TP10CR Transmit Port 10 Control Register 6.2
022C TP11CR Transmit Port 11 Control Register 6.2
0230 TP12CR Transmit Port 12 Control Register 6.2
0234 TP13CR Transmit Port 13 Control Register 6.2
0238 TP14CR Transmit Port 14 Control Register 6.2
023C TP15CR Transmit Port 15 Control Register 6.2
