background image

DS31256

16 of 181

PIN NAME

TYPE

FUNCTION

C15

RD9

I

Receive Serial Data for Port 9

A14

RD10

I

Receive Serial Data for Port 10

B12

RD11

I

Receive Serial Data for Port 11

C10

RD12

I

Receive Serial Data for Port 12

A7

RD13

I

Receive Serial Data for Port 13

D7

RD14

I

Receive Serial Data for Port 14

A3

RD15

I

Receive Serial Data for Port 15

C2

RS0

I

Receive Serial Sync for Port 0

E3

RS1

I

Receive Serial Sync for Port 1

F1

RS2

I

Receive Serial Sync for Port 2

H1

RS3

I

Receive Serial Sync for Port 3

M2

RS4

I

Receive Serial Sync for Port 4

P2

RS5

I

Receive Serial Sync for Port 5

R3

RS6

I

Receive Serial Sync for Port 6

T4

RS7

I

Receive Serial Sync for Port 7

C17

RS8

I

Receive Serial Sync for Port 8

A16

RS9

I

Receive Serial Sync for Port 9

B14

RS10

I

Receive Serial Sync for Port 10

C12

RS11

I

Receive Serial Sync for Port 11

B10

RS12

I

Receive Serial Sync for Port 12

C8

RS13

I

Receive Serial Sync for Port 13

A5

RS14

I

Receive Serial Sync for Port 14

B4

RS15

I

Receive Serial Sync for Port 15

D3

TC0

I

Transmit Serial Clock for Port 0

E1

TC1

I

Transmit Serial Clock for Port 1

G2

TC2

I

Transmit Serial Clock for Port 2

J3

TC3

I

Transmit Serial Clock for Port 3

N1

TC4

I

Transmit Serial Clock for Port 4

P3

TC5

I

Transmit Serial Clock for Port 5

U1

TC6

I

Transmit Serial Clock for Port 6

V2

TC7

I

Transmit Serial Clock for Port 7

A18

TC8

I

Transmit Serial Clock for Port 8

D14

TC9

I

Transmit Serial Clock for Port 9

C13

TC10

I

Transmit Serial Clock for Port 10

A12

TC11

I

Transmit Serial Clock for Port 11

A9

TC12

I

Transmit Serial Clock for Port 12

B7

TC13

I

Transmit Serial Clock for Port 13

C6

TC14

I

Transmit Serial Clock for Port 14

D5

TC15

I

Transmit Serial Clock for Port 15

C1

TD0

O

Transmit Serial Data for Port 0

G4

TD1

O

Transmit Serial Data for Port 1

H3

TD2

O

Transmit Serial Data for Port 2

J1

TD3

O

Transmit Serial Data for Port 3

N3

TD4

O

Transmit Serial Data for Port 4

T1

TD5

O

Transmit Serial Data for Port 5

U2

TD6

O

Transmit Serial Data for Port 6

V3

TD7

O

Transmit Serial Data for Port 7

C16

TD8

O

Transmit Serial Data for Port 8

A15

TD9

O

Transmit Serial Data for Port 9

A13

TD10

O

Transmit Serial Data for Port 10

C11

TD11

O

Transmit Serial Data for Port 11

C9

TD12

O

Transmit Serial Data for Port 12
