DS31256

145 of 181

Register Name:

PRCC1

Register Description: PCI Revision ID/Class Code Register 1
Register Address:

0x108h

LSB

Revision ID (Read Only/Set to 00h)

Class Code (Read Only/Set to 00h)

Class Code (Read Only/Set to 80h)

MSB

Class Code (Read Only/Set to 06h)


Bits 0 to 7/Revision ID.
These read-only bits identify the specific device revision, selected by Dallas
Semiconductor.

Bits 8 to 15/Class Code Interface. These read-only bits identify the subclass interface value for the device and
are fixed at 00h. See Appendix D of PCI Local Bus Specification Revision 2.1 for details.

Bits 16 to 23/Class Code Subclass. These read-only bits identify the subclass value for the device and are fixed at
80h, indicating “Other Bridge Device.” See Appendix D of PCI Local Bus Specification Revision 2.1 for details.

Bits 24 to 31/Class Code Base Class. These read-only bits identify the base class value for the device and are
fixed at 06h, which indicate “Bridge Devices.” See Appendix D of PCI Local Bus Specification Revision 2.1 for
details.

Register Name:

PLTH1

Register Description: PCI Latency Timer/Header Type Register 1
Register Address:

0x10Ch

LSB

Cache Line Size (Read Only/Set to 00h)

Latency Timer (Read Only/Set to 00h)

Header Type (Read Only/Set to 80h)

MSB

BIST (Read Only/Set to 00h)


Bits 0 to 7/Cache Line Size.
These read-only bits are forced to 0.

Bits 8 to 15/Latency Timer. These read-only bits are forced to 0 by the device since the device cannot act as a
bus master.

Bits 16 to 23/Header Type. These read-only bits are forced to 80h, which indicate a multifunction device.

Bits 24 to 31/Built-In Self-Test (BIST). These read-only bits are forced to 0.
