DS31256

37 of 181

5.3.2 Status and Interrupt Register Description


Register Name:

SM

Register Description: Status Master Register
Register Address:

0020h

Bit

# 7 6 5 4 3 2 1 0

Name n/a n/a

n/a

PPERR PSERR SBERT STCOFA SRCOFA

Default

0 0 0 0 0 0 0 0

Bit

# 15 14 13 12 11 10 9 8

Name LBINT LBE n/a

n/a

n/a

n/a

n/a

n/a

Default

0 0 0 0 0 0 0 0

Note: Bits that are underlined are read-only; all other bits are read-write.

Bit 0/Status Bit for Change-of-Frame Alignment (SRCOFA). This status bit is set to 1 if one or more of the
receive ports has experienced a COFA event. The host must read the RCOFA bit in the receive port control
registers (RP[n]CR) of each active port to determine which port or ports has seen the COFA. The SRCOFA bit is
cleared when read and is not set again until the one or more receive ports has experienced another COFA. If
enabled through the SRCOFA bit in the interrupt mask for SM (ISM), the setting of this bit causes a hardware at
the PCI bus through the PINTA signal pin and also at the LINT if the local bus is in configuration mode.

Bit 1/Status Bit for Transmit Change-of-Frame Alignment (STCOFA). This status bit is set to 1 if one or more
of the transmit ports has experienced a COFA event. The host must read the TCOFA bit in the transmit port
control registers (TP[n]CR) of each active port to determine which port or ports has seen the COFA. The STCOFA
bit is cleared when read and is not set again until one or more transmit ports has experienced another COFA. If
enabled through the STCOFA bit in the ISM, the setting of this bit causes a hardware interrupt at the PCI bus
through the PINTA signal pin and also at the LINT if the local bus is in configuration mode.

Bit 2/Status Bit for Change of State in BERT (SBERT). This status bit is set to 1 if there is a major change of
state in the BERT receiver. A major change of state is defined as either a change in the receive synchronization
(i.e., the BERT has gone into or out of receive synchronization), a bit error has been detected, or an overflow has
occurred in either the bit counter or the error counter. The host must read the status bits of the BERT in the BERT
status register (BERTEC0) to determine the change of state. The SBERT bit is cleared when read and is not set
again until the BERT has experienced another change of state. If enabled through the SBERT bit in the ISM, the
setting of this bit causees a hardware interrupt at the PCI bus through the PINTA signal pin and also at the LINT if
the local bus is in configuration mode.

Bit 3/Status Bit for PCI System Error (PSERR).
This status bit is a software version of the PCI bus hardware
pin PSERR. It is set to 1 if the PCI bus detects an address parity error or other PCI bus error. The PSERR bit is
cleared when read and is not set again until another PCI bus error has occurred. If enabled through the PSERR bit
in the ISM, the setting of this bit causes a hardware interrupt at the PCI bus through the PINTA signal pin and also
at the LINT if the local bus is in configuration mode. This status bit is also reported in the control/status register in
the PCI configuration registers (Section

10

).

Bit 4/Status Bit for PCI System Error (PPERR). This status bit is a software version of the PCI bus hardware
pin PPERR. It is set to 1 if the PCI bus detects parity errors on the PAD and PCBE buses as experienced or
reported by a target. The PPERR bit is cleared when read and is not set again until another parity error has been
detected. If enabled through the PPERR bit in the interrupt mask for SM (ISM), the setting of this bit causes a
hardware interrupt at the PCI bus through the PINTA signal pin and also at the LINT if the local bus is in
configuration mode. This status bit is also reported in the control/status register in the PCI configuration registers
(Section

10

).
