13. AC

CHARACTERISTICS

ABSOLUTE MAXIMUM RATINGS

Voltage on Any Lead with Respect to V

SS

(except V

DD

) -0.3V

to

5.5V

Supply Voltage (V

DD

) with Respect to V

SS

-0.3V

to

3.63V

Operating Temperature/Ambient Temperature Under Bias

0°C to +70°C

Junction Temperature Under Bias

£125°C

Storage Temperature Range

-55°C to +125°C

Soldering Temperature Range

See IPC/JEDEC J-STD-020A

ESD Tolerance (Note 1)

Class 2 (2000V→4000V HBM:

1.5kΩ,100pF)


Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only,
and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is
not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.


RECOMMENDED DC OPERATING CONDITIONS

(T

A

= 0°C to +70°C)

PARAMETER SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Logic 1

V

IH

(Notes 2, 3)

2.2

5.5

V

Logic 0

V

IL

(Note 2)

-0.3

+0.8

V

Supply

V

DD

3.0

3.6

V

DC CHARACTERISTICS

(V

DD

= 3.0V to 3.6V, T

A

= 0°C to +70°C.)

PARAMETER SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Supply Current at V

DD

= 3.6V

I

DD

(Note

4)

475 mA

Pin Capacitance

C

IO

7 pF

Schmitt Hysteresis

V

TH

0.6 V

Input Leakage

I

IL

(Note 5)

-10 +10

mA

Input Leakage (with pullups)

I

ILP

(Note 5)

-500 +500

mA

Output Leakage

I

LO

(Note 6)

-10 +10

mA

Output Current (2.4V)

I

OH

-4.0

mA

Output Current (0.4V)

I

OL

+4.0

mA

Output Capacitance

C

OUT

(Note

1)

25 pF

Output Capacitance

C

OUTB

(Note

1)

50 pF

Note 1: C

OUTB

refers to bus-related outputs (PCI and local bus); C

OUT

refers to all other outputs.

Note 2: Assumes a reasonably noise-free environment.
Note 3: The PCI 2.1 Specification states that V

IH

should be V

DD

/2 in a 3.3V signaling environment, and 2.0V in a 5V signaling environment.

Note 4: Measured 170mA with RC0 to RC39 and TC0 to TC39 = 2.048MHz, PCLK = 33MHz, constant traffic on all ports.
Note 5: 0V < V

IN

< V

DD

Note 6: Outputs in three-state.
Note 7: The typical values listed above are not production tested.
Note 8:
Dallas Semiconductor Communications devices are tested in accordance with ESDA STM 5.1-1998.
