Monitoring, Reporting, Notifications, and the Event Log
Data Protector Notifications
Chapter 7 350
Windows NT To configure Windows NT SNMP traps, proceed as follows:
1. On the Cell Manager, open Control Panel , Network , Services . If
there is no SNMP Service entry in the list of network services under
the Services tab, perform step 2. If there is, skip step 2.
2. Click Add and select SNMP Service . Click OK . Insert the Windows
NT installation CD, or provide an alternative path to the requested
files. Click
Continue .
3. Select SNMP Service and click Properties . Select the Traps tab
and enter public in the Community Name drop-down list. Click Add
next to the Community Name drop-down list.
4. Click Add under Trap Destinations text box and enter the
hostname of the VPO Management Server. Click Add . Repeat this
step to add any number of VPO Management Servers.
5. Click OK . Click Close .
6. Start omnisnmp .
Windows
2000/XP/Server
2003 To configure Windows 2000/XP/Server 2003 SNMP traps, proceed as
follows:
1. On the Cell Manager, open Settings , Network and Dial-up
Connections .
2. In the Advanced menu, select Optional Networking Components
to start the wizard.
3. In the wizard, select Management and Monitoring tools and click
Next .
4. Follow the wizard to install the Management and Monitoring tools.
5. Open Control Panel , Administrative Tools , Services .
6. Right-click SNMP Service and select Properties .
a. Select the Traps tab and enter public in the Community name
text box and the hostname of the VPO Management Server in the
Trap Destinations text box.
b. Select the Security tab. Under Accepted community names ,
select the community public , click Edit and set Community
rights to READ CREATE .
c. Confirm your settings.
