An error may occur during the comparison. If an error is displayed, press any key to cancel the error display
and return to the o3-01 display. Error displays and their meanings are shown below. (Refer to Chapter 7
Errors when Using Digital Operator Copy Function.)
Application Precautions
When using the copy function, check that the following settings are the same between the MxC and the digital
operator.
•
If using the copy function, make sure communications are off-line or the option card has been removed.
•
If the power supply of the MxC is turned off while executing the copy function, a CPF03 fault (EEPROM
error) will occur.
6
Set the changed data using the DATA/ENTER key. The VERIFY function will
start.
7
If the VERIFY function ends normally, “VERIFY COMPLETE” appears on the
digital operator.
8
The display returns to o3-01 after any key is pressed.
Error Display
Meaning
Verify error (Settings in the digital operator and the MxC do not match).
•
MxC product and type
•
MxC capacity and voltage
•
Software number
•
Control method
Table 6.3 VERIFY Function Procedure (Continued)
Step
No.
Digital Operator Display
Explanation
VERIFY
-ADV-
DATA VERIFYING
VERIFY
-ADV-
VERIFY COMPLETE
Copy Funtion Sel
-ADV-
o3 -
01
=0
COPY SELECT
*0*
VYE
VERIFY ERROR
