EDIUS Neo — User Reference Guide
Section 6 — Effects and Titles
4.
Configure the effect settings per the explanations below and click the
OK
button to close the dialog.
Display Switching
Select “Key Display” to display in black in the Recorder the parts of the
video that will be cut out based on the current color selection. See
for an example based on the eye dropper color selection of the
blue water in the background.
Figure 518. Chromakey Key Display
Select the ‘Histogram Display” option to display a histogram of the colors
that can be selected for elimination.
Note
The Histogram Display option is not available with the eye dropper color
selector.
for an example of a histogram display and color selection
with the color circle.
Figure 519. Chromakey Histogram Display and Color Selection
