RS232/Ethernet interfaces
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
82
LED status
The status of the LEDs is stored in a byte as follows:
} Bit 0 = 1: LED OFAULT is lit or flashes
} Bit 1 = 1: LED IFAULT is lit or flashes
} Bit 2 = 1: LED FAULT is lit or flashes
} Bit 3 = 1: LED DIAG is lit or flashes
} Bit 4 = 1: LED RUN is lit
} Bit 5-7: Reserved
Tables
Further information can be requested in table form.
A table consists of one or more segments. Each segment is made up of 13 Bytes.
The communications partner requests the required data using the table number and seg-
ment number. The PNOZmulti repeats the two numbers and sends the requested data.
There are a total of 10 tables, with the following contents:
Table 1: Configuration
Table 2: Reserved
Table 3: State of inputs
Table 4: State of outputs
Table 5: Status of LED
Table 6: Reserved
Table 7: Diagnostic word
Table 8: Element types
Table 9: Transfer/state of the expanded virtual inputs and outputs
Table 10 State of the virtual inputs and outputs on the integrated link inter-
face on the PNOZ mm0.2p
Table 11 State of the safe inputs and outputs on the safe Ethernet connec-
tion
Element types The element type's byte is entered in Table 8
The content of the tables is described in detail in the Appendix.
Requests
A request is defined via the request number and segment number.
The following requests are available:
Request
No.
Segment
No. Meaning
0x14 0x01 Send virtual inputs to the PNOZmulti
0x14 0x02 Send virtual inputs to the PNOZmulti, request state of the vir-
tual outputs and LED status from the PNOZmulti
0x2C 0x02 Request state of virtual inputs and outputs from PNOZmulti
0x2F Send data from the PNOZmulti in table form
0x53 Request all input and output data from PNOZmulti
5.6.3
5.6.4
5.7
