Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
32
Index
(hex)
Input
Byte
Content Example/Comment
0x2003:31
...
0x2003:35 432
...
436 0 A15 A14 A13 A12 A11 A10 A9 A8
If an output has a high signal, the corresponding Bit will
contain "1"; if the output is open (low signal), the Bit will
contain "0".
INFORMATION
On the base units PNOZmulti Mini, the status of the con-
figurable inputs/outputs is only displayed if they are con-
figured as outputs in the PNOZmulti Configurator.
Assignment of Bytes on the
base units PNOZmulti Mini:
0x2003:36 437 O8 ... O15 1st
expansion module, right Sub-Index 21:
0
0 0 0 IM3 IM2 IM1 IM0
0x2003:37 438 O8 ... O15 2nd
expansion module, right Sub-Index 23:
T3
M23
T2
M22 T1
M21 T0;20 IM19 IM18 IM17 IM16
0x2003:38 439 O8 ... O15 3rd
expansion module, right
0x2003:39 440 O8 ... O15 4th
expansion module, right
0x2003:3A 441 O8 ... O15 5th
expansion module, right
0x2003:3B 442 O8 ... O15 6th expansion
module right
0x2003:3C 443 O8 ... O15 7th
expansion module, right
0x2003:3D Input
Byte
444
O8 ... O15 8th
expansion module, right
0x2003:3E
...
0x2003:40 445
...
447 Reserved
