Pilz PNOZ mm0p 24VDC User Manual
Page 24
Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
24
Index (hex) Name
Content
Example/explanation
0x2000:40
Input Byte 63
i0 ... i7 Safe
Ethernet connection
Inputs, safe Ethernet connection
0x2000:41
Input Byte 64
i8 ... i15 Safe
Ethernet connection
0x2000:42
Input Byte 65
i16 ... i23 Safe
Ethernet connection
0x2000:43
Input Byte 66
i24 ... i31 Safe
Ethernet connection
0x2000:44
Input Byte 67
i32 ... i39 Safe
Ethernet connection
0x2000:45
Input Byte 68
i40 ... i47 Safe
Ethernet connection
0x2000:46
…
0x2000:47
Input Byte 69
…
Input Byte 70
Reserved.
0x2000:48
Input Byte 71
o0 ... o7 Safe
Ethernet connection
Outputs, safe Ethernet connection
0x2000:49
Input Byte 72
o8 ... o15 Safe
Ethernet connection
0x2000:4A
Input Byte 73
o16 ... o23 Safe
Ethernet connection
0x2000:4B
Input Byte 74
o24 ... o31 Safe
Ethernet connection
0x2000:4C
Input Byte 75
o32 ... o39 Safe
Ethernet connection
0x2000:4D
Input Byte 76
i40 ... i47 Safe
Ethernet connection
0x2000:4E
…
0x2000:4F
Input Byte 77
…
Input Byte 78
Reserved.
0x2000: 50
Input Byte 79
I0 ... I7
1st expansion module,
left
Virtual inputs on the 2nd link module PNOZ ml1p:
0x2000:51
Input Byte 80
I8 ... I15
1st expansion module,
left
0x2000:52
Input Byte 81
I16 ... I23
1st expansion module,
left
Sub-Index 54:
I7
I6
I5
I4
I3
I2
I1
I0
0x2000:53
Input Byte 82
I24 ... I31
1st expansion module,
left
Sub-Index 55:
I15
I14
I13
I12
I11
I10
I9
I8
