Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
64
461 FAULT 1st expansion module, left Depending on the LED status, the following Hex code will
be in Byte 461 ... 466:
00 hex: LED off
FF hex: LED on
30 hex: LED flashes
462 FAULT 2nd expansion module, left
463 FAULT 3rd expansion module, left
464 FAULT 4th expansion module, left
465 FAULT 5th expansion module, left
466 FAULT 6th expansion module, left
467 ...
511
Reserved
Configuration
These bytes contain the PNOZmulti's configuration data
Byte Contents Example/Comment
512 Data transfer Byte 512 = 1: Bit 1 = 1: All configuration
data has been downloaded to the fieldbus
module
513 Reserved
514 Number of elements Number of configured elements with Ele-
ment ID
515 ...
527
Reserved
528 ...
531
Product number (hex) Product number 733 100: 000BCBEC hex
Byte 528: 00, Byte 529: 0B, Byte 530:
CB,Byte 531: EC
532 ...
535
Unit version (hex) Unit version 20: 14 hex
Byte 532: 00, Byte 533: 00, Byte 534:
00,Byte 535: 14
536 …
539
Serial number (hex) Serial number 123 456: 0001E240 hex.
Byte 536: 00, Byte 537: 01, Byte 538:
E2,Byte 539: 40
540 ...
541
Check sum safe (hex) Check sum A1B2 hex:
Byte 540: A1, Byte 541: B2
542 ...
543
Overall project check sum (hex) Check sum 3C5A hex:
Byte 542: 3C, Byte 543: 5A
544 ...
547
Reserved
548 ...
551
Project creation date (hex) Creation date: 28.11.2003
Byte 548: 1C, Byte 549: 0B, Byte 550:
07,Byte 551: D3
552 ...
554
Reserved
555 Configuration, fieldbus module/inte-
grated interface
Byte 555 contains the Hex code for a
fieldbus module (installed on the left) or
for inputs and outputs via the integr. inter-
face (see Table 1 Seg 2 Byte 0)
4.5.3.4
