Table 3
Table 3 consists of 3 segments, each of which has 13 Bytes. It contains the status of the in-
puts
Information
On the base units PNOZmulti Mini, the status of the configurable inputs/out-
puts is only displayed if they are configured as inputs in the PNOZmulti Con-
figurator.
Segment Byte Content Example/Comment
0
0 I0 ... I7 base unit,
IM0 ... I7 base unit Mini For example: The safety system consists of one base unit
PNOZ m1p and one expansion module PNOZ mi1p
1 I8 ... I15 base unit
I8 ... I15 base unit Mini
2 I16 ... I19 base unit
IM16 ... IM19 base unit
Mini
Byte 0 I7 I6 I5 I4 I3 I2 I1 I0 PNOZ m1p
Byte 1 I15 I14 I13 I12 I11 I10 I9 I8 PNOZ m1p
3 0 Byte 2 0 0 0 0 I19 I18 I17 I16 PNOZ m1p
4 0 Byte 3 0 0 0 0 0 0 0 0
5 I0 ... I7
1st expansion module right
Byte 4 0 0 0 0 0 0 0 0
0
6 I0 ... I7
2nd expansion module
right
Byte 5 I7 I6 I5 I4 I3 I2 I1 I0 PNOZ
mi1p
7 I0 ... I7
3rd expansion module right If an input has a high signal, the corresponding bit will be "1";
if an input has a low signal, the bit will be "0".
Virtual inputs on the 2nd link module
PNOZ ml1p
8 I0 ... I7
4th expansion module right
9 I0 ... I7
5th expansion module right
10 I0 ... I7
6th expansion module right
11 I0 ... I7
7th expansion module right
12 I0 ... I7
8th expansion module right
1 0 I0 ... I7
1st expansion module, left
1 I8 ... I15
1st expansion module, left
2 I16 ... I23
1st expansion module, left
