Page 39
Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
39
Object Directory
Index 2000
This index contains the output data
Sub-In-
dex (dec) Content
Example/explanation
1
Outputs Bit 0 … 7 fieldbus module For information on the sub-indices please see chapter enti-
tled "Communication with fieldbus systems"
2
Outputs Bit 8 … 15 fieldbus module
3
Outputs Bit 16 … 23 fieldbus mod-
ule
4
LED status
5
Table number
6
Segment number
7
Byte 0
8
Byte 1
9
Byte 2
10
Byte 3
11
Byte 4
12
Byte 5
13
Byte 6
14
Byte 7
15
Byte 8
16
Byte 9
17
Byte 10
18
Byte 11
19
Byte 12
20 ... 63
Reserved
64
i0 ... i7 Safe Ethernet connection
Inputs on the safe Ethernet connection
65
i8 ... i15 Safe Ethernet connection
66
i16 ... i23 Safe Ethernet connection
67
i24 ... i31 Safe Ethernet connection
68
i32 ... i39 Safe Ethernet connection
69
i40 ... i47 Safe Ethernet connection
70 ... 71
Reserved
4.3.3
4.3.3.1
