Modbus/TCP

Operating Manual PNOZmulti communication interfaces
1001154-EN-13

102

Register
(3x)

Discrete Input
(1x)

Content

High Byte

Low Byte

834

13359... 13344 Fieldbus module software

version

Version

Reserved

835

13375... 13360 Reserved

836

13391... 13376 Reserved

837

13407... 13392 Reserved

838

13423... 13408 Reserved

839

13439... 13424 Reserved

840

13455... 13440 Configuration, expansion

module left

Slot 2

Slot 1

841

13471... 13456 Configuration, expansion

module left

Slot 4

Slot 3

842

13487... 13472 Configuration, expansion

module left

Slot 6

Slot 5

843

13503... 13488 Reserved

844

13519... 13504 Reserved

845

13535... 13520 Reserved

846

13551... 13536 Reserved

State of the inputs from the base unit and expansion modules
The table below describes the Modbus/TCP data areas that contain the state of the inputs
from the base unit and expansion modules.
Relevant areas for the data are defined in the Modbus/TCP data areas Discrete Inputs (1x)
and Input Register (3x). Read access is available to these data areas.

Register
(3x)

Coil/
Discrete Input
(1x)

Content

High Byte

Low Byte

847

13567... 13552 Base unit I0 - I15

Base unit Mini IM0 ... I15

i15 ….i8

i7 ….i0

848

13583... 13568 Base unit I16 – I19

Base unit Mini I16 ...

IM19

Reserved

i23...i16

849

13599... 13584 Reserved /

Expansion module, right

Right 1 (i7...

i0)

Reserved

850

13615... 13600 Expansion module, right

Right 3 (i7...

i0)

Right 2 (i7...i0)

851

13631... 13616 Expansion module, right

Right 5 (i7...

i0)

Right 4 (i7...i0)

852

13647... 13632 Expansion module, right

Right 7 (i7...

i0)

Right 6 (i7...i0)
