Modbus/TCP
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
111
Register
(3x)
Coil/
Discrete Input
(1x)
Content
High Byte
Low Byte
1024
16399... 16384 Diagnostic word 73
Bit 15… 8
Bit 7… 0
1025
16415... 16400 Diagnostic word 74
Bit 15… 8
Bit 7… 0
1026
16431... 16416 Diagnostic word 75
Bit 15… 8
Bit 7… 0
1027
16447... 16432 Diagnostic word 76
Bit 15… 8
Bit 7… 0
1028
16463... 16448 Diagnostic word 77
Bit 15… 8
Bit 7… 0
1029
16479... 16464 Diagnostic word 78
Bit 15… 8
Bit 7… 0
1030
16495... 16480 Diagnostic word 79
Bit 15… 8
Bit 7… 0
1031
16511... 16496 Diagnostic word 80
Bit 15… 8
Bit 7… 0
1032
16527... 16512 Diagnostic word 81
Bit 15… 8
Bit 7… 0
1033
16543... 16528 Diagnostic word 82
Bit 15… 8
Bit 7… 0
1034
16559... 16544 Diagnostic word 83
Bit 15… 8
Bit 7… 0
1035
16575... 16560 Diagnostic word 84
Bit 15… 8
Bit 7… 0
1036
16591... 16576 Diagnostic word 85
Bit 15… 8
Bit 7… 0
1037
16607... 16592 Diagnostic word 86
Bit 15… 8
Bit 7… 0
1038
16623... 16608 Diagnostic word 87
Bit 15… 8
Bit 7… 0
1039
16639... 16624 Diagnostic word 88
Bit 15… 8
Bit 7… 0
1040
16655... 16640 Diagnostic word 89
Bit 15… 8
Bit 7… 0
1041
16671... 16656 Diagnostic word 90
Bit 15… 8
Bit 7… 0
1042
16687... 16672 Diagnostic word 91
Bit 15… 8
Bit 7… 0
1043
16703... 16688 Diagnostic word 92
Bit 15… 8
Bit 7… 0
1044
16719... 16704 Diagnostic word 93
Bit 15… 8
Bit 7… 0
1045
16735... 16720 Diagnostic word 94
Bit 15… 8
Bit 7… 0
1046
16751... 16736 Diagnostic word 95
Bit 15… 8
Bit 7… 0
1047
16767... 16752 Diagnostic word 96
Bit 15… 8
Bit 7… 0
1048
16783... 16768 Diagnostic word 97
Bit 15… 8
Bit 7… 0
1049
16799... 16784 Diagnostic word 98
Bit 15… 8
Bit 7… 0
1050
16815... 16800 Diagnostic word 99
Bit 15… 8
Bit 7… 0
1051
16831... 16816 Diagnostic word 100
Bit 15… 8
Bit 7… 0
1052
16847... 16832 Reserved
1053
16863... 16848 Reserved
1054
16879... 16864 Reserved
1055
16895... 16880 Reserved
1056
16911... 16896 Reserved
1057
16927... 16912 Reserved
1058
16943... 16928 Reserved
1059
16959... 16944 Reserved
