Diagnostic word
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
134
Bit Message Comment
14 Threshold value monitoring for the threshold L7 has
been activated (Status =1).
15 Threshold value monitoring for the threshold L8 has
been activated (Status =1).
Cascading
} Cascading output
Bit Message Comment
8 The signal at the CO output is faulty. For example: Fault, short circuit at CO cas-
cading output
} Cascading input
Bit Message Comment
8 The signal at the CI input is faulty. CI input is not connected to a CO output.
Logic elements
} RS flip-flop
Bit Message Comment
2 Input S is ready to set. Input S is “0” after reset
8 There is a 1 signal at input R. Input R =1
} Reset element
Bit Message Comment
2 Reset button is ready for reset. Input signal is present, reset button can be
operated.
3 Reset button is waiting for the input signal. No input signal is present.
} Speed monitors PNOZ ms1p, PNOZ ms2p <= V 1.9
Bit Message Comment
2 Speed monitor is ready for reset. Manual or monitored reset was configured.
The reset button has not yet been operated.
3 Cannot monitor the speed because no speed has been
selected.
With inputs n1 to n8, standstill or speed
monitoring is initialised by a “1” signal. Only
one input may occupy the "1" signal status.
8 Selected speed has been exceeded. The speed at one of the active inputs n1 to
n8 has been exceeded.
8.5.2
8.5.3
