Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
42
Sub-In-
dex (dec) Content Example/explanation
120 O0 ... O7 5th expansion module,
left
If an output has a high signal, the corresponding Bit will
contain "1"; if the output is open (low signal), the Bit will
contain "0".
121 O8 ... O15 5th expansion module,
left
122 O16 ... O23 5th expansion module,
left
123 O24 ... O31 5th expansion module,
left
124 O0 ... O7 6th expansion module,
left
125 O8 ... O15 6th expansion module,
left
126 O16 ... O23 6th expansion module,
left
127 O24 ... O31 6th expansion module,
left
128 Reserved
Index 2001 and 2002
This index contains the diagnostic words and the output bits for the Element IDs.
Index (hex) 2001:
Sub-In-
dex
(dec) Contents Example/explanation
1 Low Byte diagnostic word.
Element ID=1 The diagnostic word is displayed in the PNOZmulti Configurator
and on the PVIS expanded diagnostics (see chapter entitled Diag-
nostic word [ 128] and the online help for the PNOZmulti Config-
urator)
Element ID = 1,
e.g. diagnostic word of E-STOP:
Low Byte:
...
100
Low Byte diagnostic word.
Element ID=100
0 0 0 0 0 0 1 0
Message: Pushbutton operated
4.3.3.2
