Fieldbus modules
Operating Manual PNOZmulti communication interfaces
1001154-EN-13
67
Element types
These bytes contain the element types
Byte Content Example/explanation
640 Element type. Element ID = 1 Element with ID = 1: Single-pole semicon-
ductor output with feedback loop
Byte 640: 51 hex
See list containing the
Element types [
173] in the Appendix
... ...
739 Element type. Element ID = 100
740 ...
2047
Reserved
Input data
These bytes contain the input data
Byte Content Example/explanation
2048 Inputs Bit 0 … 7 See chapter entitled "Basics", under Input data
(to the PNOZmulti) [ 13]
2049 Inputs Bit 8 … 15
2050 Inputs Bit 16 … 23
2051 Reserved
2052 Table number
2053 Segment number
2054 Byte 0
2055 Byte 1
2056 Byte 2
2057 Byte 3
2058 Byte 4
2059 Byte 5
2060 Byte 6
2061 Byte 7
2062 Byte 8
2063 Byte 9
2064 Byte 10
2065 Byte 11
2066 Byte 12
2067 ...
2111
Reserved
4.5.3.5
4.5.3.6
