Maxim Integrated High-Speed Microcontroller - Manual (Page 75)

High-Speed Microcontroller User’s Guide
Rev: 062210 75 of 176
Table 5-B. Instruction Speed Summary
INSTRUCTION CATEGORY QUANTITY SPEED ADVANTAGE
Total Instructions: One Cycle, One Byte 37 3.0
Total Instructions: Two Cycle, One Byte 4 3.0
Total Instructions: Two Cycle, Two Bytes X1.5 27 1.5
Total Instructions: Two cycle, Two Bytes X3.0 11 3.0
Total Instructions: Three Cycle, One Byte 4 2.0
Total Instructions: Three Cycle, Two Bytes 8 2.0
Total Instructions: Three Cycle, Three Bytes 7 2.0
Total Instructions: Four Cycle, One Byte 2 1.5
Total Instructions: Four Cycle, Three Bytes 9 1.5
Total Instructions: Five Cycle, One Byte 2 2.4
Average Across All Instructions 111 2.3
INSTRUCTION CATEGORY QUANTITY SPEED ADVANTAGE
Total Op Codes: One Cycle, One Byte 126 3.0
Total Op Codes: Two Cycle, One Byte 6 3.0
Total Op Codes: Two Cycle, Two Bytes X1.5 35 1.5
Total Op Codes: Two Cycle, Two Bytes X3.0 27 3.0
Total Op Codes: Three Cycle, One Byte 4 2.0
Total Op Codes: Three Cycle, Two Bytes 29 2.0
Total Op Codes: Three Cycle, Three Bytes 7 2.0
Total Op Codes: Four Cycle, One Byte 2 1.5
Total Op Codes: Four Cycle, Three Bytes 17 1.5
Total Op Codes: Five Cycle, One Byte 2 2.4
Average Across All Instructions 255 2.5
