High-Speed Microcontroller User’s Guide
Rev: 062210 30 of 176
4.2.11 Timer 0 LSB (TL0)
7 6 5 4 3 2 1 0
SFR 8Ah TL0.7 TL0.6 TL0.5 TL0.4 TL0.3 TL0.2 TL0.1 TL0.0
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
R = Unrestricted Read, W = Unrestricted Write, -n = Value after Reset
TL0.7–TL0.0
Bits 7–0 Timer 0 LSB. This register contains the least significant byte of Timer 0.
4.2.12 Timer 1 LSB (TL1)
7 6 5 4 3 2 1 0
SFR 8Bh TL1.7 TL1.6 TL1.5 TL1.4 TL1.3 TL1.2 TL1.1 TL1.0
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
R = Unrestricted Read, W = Unrestricted Write, -n = Value after Reset
TL1.7–TL1.0
Bits 7–0 Timer 1 LSB. This register contains the least significant byte of Timer 1.
4.2.13 Timer 0 MSB (TH0)
7 6 5 4 3 2 1 0
SFR 8Ch TH0.7 TH0.6 TH0.5 TH0.4 TH0.3 TH0.2 TH0.1 TH0.0
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
R = Unrestricted Read, W = Unrestricted Write, -n = Value after Reset
TH0.7–TH0.0
Bits 7–0 Timer 0 MSB. This register contains the most significant byte of Timer 0.
4.2.14 Timer 1 MSB (TH1)
7 6 5 4 3 2 1 0
SFR 8Dh TH1.7 TH1.6 TH1.5 TH1.4 TH1.3 TH1.2 TH1.1 TH1.0
RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0 RW-0
R = Unrestricted Read, W = Unrestricted Write, -n = Value after Reset
TH1.7–TH1.0
Bits 7–0 Timer 1 MSB. This register contains the most significant byte of Timer 1.
