4.2.42 Watchdog Control (WDCON)
7 6 5 4 3 2 1 0
SFR D8h SMOD POR EPFI PFI WDIF WTRF EWT RWT
RW-0 RT-* RW-0 RW-* RT-0 RT-* RT-* RT-0
R = Unrestricted Read, W = Unrestricted Write, T = Timed Access Write Only, -n = Value after Reset, * = See Description
SMOD
Bit 7 Serial Modification. This bit controls the doubling of the serial port 1 baud rate in
modes 1, 2, and 3.
0 = Serial port 1 baud rate operates at normal speed
1 = Serial port 1 baud rate is doubled.
POR
Bit 6 Power-On Reset Flag. This bit indicates whether the last reset was a power-on reset.
This bit is typically interrogated following a reset to determine if the reset was caused
by a power-on reset. It must be cleared by a Timed Access write before the next reset of
any kind or the software may erroneously determine that another power-on reset has
occurred. This bit is set following a power-on reset and unaffected by all other resets.
Note: This bit is not Timed Access protected on the DS80C310.
0 = Last reset was from a source other than a power-on reset.
1 = Last reset was a power-on reset.
EPFI
Bit 5 Enable Power-Fail Interrupt. This bit enables/disables the ability of the internal
bandgap reference to generate a power-fail interrupt when V
CC
falls below
approximately 4.5V. While in Stop mode, both this bit and the Bandgap Select bit, BGS
(
EXIF .0), must be set to enable the power-fail interrupt.
0 = Power-fail interrupt disabled.
1 = Power-fail interrupt enabled during normal operation. Power-fail interrupt enabled
in Stop mode if BGS is set.
PFI
Bit 4 Power-Fail Interrupt Flag. When set, this bit indicates that a power-fail interrupt has
occurred. This bit must be cleared in software before exiting the interrupt service
routine, or another interrupt will be generated. Setting this bit in software will generate a
power-fail interrupt, if enabled.
WDIF
Bit 3 Watchdog Interrupt Flag. This bit, in conjunction with the Watchdog Timer Interrupt
Enable bit, EWDI (
EIE .4), and Enable Watchdog Timer Reset bit ( WDCON .1),
indicates if a watchdog timer event has occurred and what action will be taken. This bit
must be cleared in software before exiting the interrupt service routine, or another
interrupt will be generated. Setting this bit in software will generate a watchdog
interrupt if enabled. This bit can only be modified using a timed-access procedure.
EWT EWDI WDIF RESULT
X X 0 No watchdog event has occurred.
0 0 1 Watchdog timeout has expired. No interrupt has been generated.
0 1 1 Watchdog interrupt has occurred.
1 0 1
Watchdog timeout has expired. No interrupt has been generated.
Watchdog timer reset will occur in 512 cycles if RWT is not strobed.
1 1 1
Watchdog interrupt has occurred. Watchdog timer reset will occur in
512 cycles if RWT is not set using a Timed Access procedure.
WTRF
Bit 2
Watchdog Timer Reset Flag. When set, this bit indicates that a watchdog timer reset
has occurred. It is typically interrogated to determine if watchdog timer reset caused a
reset. It is cleared by a power- on reset, but otherwise must be cleared by software
before the next reset of any kind or software may erroneously determine that a watchdog
timer reset has occurred. Setting this bit in software will not generate a watchdog timer
reset. If the EWT bit is cleared, the watchdog timer will have no effect on this bit.
