GF-122 AERCO XPC GATEWAY
93
The LED’s indicate if the translator is speaking to the devices on the network. The LED’s should reflect
communication traffic based on the baud rate set. The higher the baud rate the LED’s would become
more solid.
LEDs Status
Power Lights when power is being supplied to the translator.
The XPC is protected by internal solid state Polyswitches on the
incoming power and network connections. These Polyswitches
are not replaceable and will reset themselves if the condition that
caused the fault returns to normal.
Rx Lights when the translator receives data from the network
segment; there is an Rx LED for Ports 1 and 2.
Tx Lights when the translator transits data from the network
segment; there is an Rx LED for Ports 1 and 2.
Run Lights based on translator health. See table below.
Error Lights based on translator health. See table below.
The Run and Error LED's indicate translator and network status.
