GATEWAY COMMUNICATIONS MANUAL
138
Modbus-To-BACnet Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
BACnet
Type:ID
Blr Addr 7
01-Fire Rate Out boilerstate_7 30009/7
 
AV:100
02-Active Setpoint effectsetpt_7 30017/7
 
AV:101
03-Net Remote Setpt setpt_7 40001/7

AV:102
05-Fire Rate In boilerload_7 30018/7
 
AV:94
06-Outlet Temp localsuptemp_7 30003/7
 
AV:95
07-Display Code dispcode_7 30001/7
 
AV:96
08-Unit Status unitstat_7 30002/7
 
AV:97
09-Run Cycles runcycles_7 30012-30013/7
 
AV:98
10-Run Hours runhours_7 30014-30015/7
 
AV:99
Deg F or Deg C m114_7 BV:16
Use Temp Scaling m101_7 BV:17
Blr Addr 8
01-Fire Rate Out boilerstate_8 30009/8
 
AV:110
02-Active Setpoint effectsetpt_8 30017/8
 
AV:111
03-Net Remote Setpt setpt_8 40001/8

AV:112
05-Fire Rate In boilerload_8 30018/8
 
AV:104
06-Outlet Temp localsuptemp_8 30003/8
 
AV:105
07-Display Code dispcode_8 30001/8
 
AV:106
08-Unit Status unitstat_8 30002/8
 
AV:107
09-Run Cycles runcycles_8 30012-30013/8
 
AV:108
10-Run Hours runhours_8 30014-30015/8
 
AV:109
Deg F or Deg C m114_8 BV:18
Use Temp Scaling m101_8 BV:19
Blr Addr 9
01-Fire Rate Out boilerstate_9 30009/9
 
AV:120
02-Active Setpoint effectsetpt_9 30017/9
 
AV:121
03-Net Remote Setpt setpt_9 40001/9

AV:122
05-Fire Rate In boilerload_9 30018/9
 
AV:114
06-Outlet Temp localsuptemp_9 30003/9
 
AV:115
07-Display Code dispcode_9 30001/9
 
AV:116
08-Unit Status unitstat_9 30002/9
 
AV:117
09-Run Cycles runcycles_9 30012-30013/9
 
AV:118
10-Run Hours runhours_9 30014-30015/9
 
AV:119
Deg F or Deg C m114_9 BV:7
Use Temp Scaling m101_9 BV:8
Page 3 of 5
