GF-122 AERCO XPC GATEWAY
21
Table 6 XPC Gateway Specifications - Continued
Specification Description
Battery 10-year Lithium CR2032 battery provides a minimum of 10,000
hours of data retention during power outages
Protection Built-in surge and transient protection circuitry - internal solid
state Polyswitches on the incoming power and network
connections.
Status Indicators LED's indicate status of communications, running, errors, and
power.
Environmental operating
range -40° to 150°F (-40° to 65.6°C), 10–95% relative humidity, non-
condensing
Overall dimensions
(without enclosure) Width 4 in. (102mm)
Height 5 in. (127mm)
Depth 1.75 in. (51mm)
Add for the LonWorks Card:
Width 1.8 in. (45.72mm)
Height 3.25 in. (82.55mm)
Depth 1.5 in. (38.1mm)
Distance apart cannot exceed ribbon cable:
9.75 in. (247.65 mm)
Mounting hole dimensions
(without enclosure) Width 2 in. (51 mm)
Height 4.8 in. (122mm)
LonWorks Option Card
1.325 in. (33.66 mm) apart – top 2 holes
.475 in. (12.07 mm) from edge
.890 in. (22.61 mm) bottom hole – from edge
Mounting hole dimensions
in enclosure Width 8.94 in. (227 mm) apart – top 2 & bottom 2 holes
Height 5.00 in. (127 mm) between top 2 & bottom 2 holes
Rommended panel depth 1.75 in. (51mm)
Weight 9 oz.
BACnet support Conforms to the Advanced Application Controller (B-AAC)
Standard Device Profile as defined in ANSI/ASHRAE Standard
135-2004 (BACnet) Annex L
Listed by UL-916 (PAZX), cUL-916 (PAZX7), FCC Part 15-Subpart B-
Class A, CE EN50082-1997
1.10 QUICK SETUP GUIDE
A Quick Setup Guide is provided as additional guidance to configuring and integrating the AERCO
XPC Communications Gateway. The guide now follows.
