GATEWAY COMMUNICATIONS MANUAL
140
Modbus-To-BACnet Protocol Mapping
1 BMS/BMS II, 12 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
BACnet
Type:ID
BMS Addr 128
01-Fire Rate Out boilerstate_13 30005/128
 
AV:31
02-Header Set Temp effectsetpt_13 30006/128
 
AV:32
03-Net Header Set Temp setpt_13 40005/128

AV:33
04-Header Temp localsuptemp_13 30002/128
 
AV:34
05-Outside Air Temp localoatemp_13 30003/128
 
AV:35
06-Display Code dispcode_13 30011/128
 
AV:36
07-Num Boilers Fired blrfired_13 30008/128
 
AV:37
08-Num Boilers Online blronline_13 30009/128
 
AV:38
09-Last Blr Fired blrlast_13 30017/128
 
AV:39
10-Boiler 1 Status blr1stat_13 30018/128
 
AV:40
11-Boiler 2 Status blr2stat_13 30019/128
 
AV:41
12-Boiler 3 Status blr3stat_13 30020/128
 
AV:48
13-Boiler 4 Status blr4stat_13 30021/128
 
AV:1
14-Boiler 5 Status blr5stat_13 30022/128
 
AV:2
15-Boiler 6 Status blr6stat_13 30023/128
 
AV:3
16-Boiler 7 Status blr7stat_13 30024/128
 
AV:4
17-Boiler 8 Status blr8stat_13 30025/128
 
AV:5
18-Net Blr 1 Status blr9stat_13 30026/128
 
AV:6
19-Net Blr 2 Status blr10stat_13 30027/128
 
AV:7
20-Net Blr 3 Status blr11stat_13 30028/128
 
AV:8
21-Net Blr 4 Status blr12stat_13 30029/128
 
AV:9
22-Net Blr 5 Status blr13stat_13 30030/128
 
AV:10
23-Net Blr 6 Status blr14stat_13 30031/128
 
AV:11
24-Net Blr 7 Status blr15stat_13 30032/128
 
AV:12
25-Net Blr 8 Status blr16stat_13 30033/128
 
AV:13
26-Net Blr 9 Status blr17stat_13 30034/128
 
AV:14
27-Net Blr 10 Status blr18stat_13 30035/128
 
AV:15
28-Net Blr 11 Status blr19stat_13 30036/128
 
AV:16
29-Net Blr 12 Status blr20stat_13 30037/128
 
AV:17
Use Metric Conversion m101_13 BV:9
Page 5 of 5
