GF-122 AERCO XPC GATEWAY
113
Register Type: Range:
Function Codes Used with this
Register Type:
Float Value
(FLOAT)
Single-Precision IEEE
floating point value
3 – Read Holding Register
6 – Preset Single Register
16 – Preset Multiple Register
Unsigned Integer
(UINT)
0 - 65535
3 – Read Holding Register
6 – Preset Single Register
16 – Preset Multiple Register
Signed Integer
(SINT)
-32768 - 32767
3 – Read Holding Register
6 – Preset Single Register
16 – Preset Multiple Register
Discrete Input (DI) 0 = Off, 1 = On 2 – Read Input Status
Discrete Output
(DO)
0 = Off, 1 = On
1 – Read Coil Status
5 – Force Single Coil
15 – Force Multiple Coils
SECTION 19 CONFORMANCE STATEMENT FOR JOHNSON N2
IMPLEMENTATION
Date: 11/22/05
Vendor Name:
OEM
Product Names: Extended Protocol Converter
Product Model Number: XPC
Applications Software Version:
HW_Exec_B
Firmware Revision:
2.03
Product Description:
The XPC is a general purpose building automation translator with custom programmable functionality,
designed for communicating through multiple protocols. N2 network points are spawned within the device
as a result of downloading graphical control programs. The XPC translator speaks the Johnson Controls
N2 Open Protocol as described in the Metasys N2 System Protocol Specification (for Vendors)
document, revision 6/13/96, and acts as an N2 Master or Slave. Further details on the N2 supported
implementation are described below.
