Modbus-To-BACnet Protocol Mapping
1 BMS II, 4 MLX Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
BACnet
Type:ID
Mlx Addr 3
01-Act Mod Lev boilerstate_3 41009/3
 
AV:18
02-Target Setpoint effectsetpt_3 41019/3
 
AV:19
03-Req Outlet Temp setpt_3 41005/3 AV:20
04-Net Direct Drive boilercmd_3 40002/3 AV:21
05-Mod Lev In boilerload_3 41201/3
 
AV:22
06-Flow Sens Temp localsuptemp_3 41003/3
 
AV:23
07-Display Code dispcode_3 30001/3
 
AV:24
11-Error Code errcode_3 40001/3
 
AV:7
08-Unit Status unitstat_3 30002/3
 
AV:25
09-Ret Flow Temp returntemp_3 41004/3
 
AV:8
Mlx Addr 4
01-Act Mod Lev boilerstate_4 41009/4
 
AV:28
02-Target Setpoint effectsetpt_4 41019/4
 
AV:29
03-Req Outlet Temp setpt_4 41005/4 AV:30
04-Net Direct Drive boilercmd_4 40002/4 AV:42
05-Mod Lev In boilerload_4 41201/4
 
AV:43
06-Flow Sens Temp localsuptemp_4 41003/4
 
AV:44
07-Display Code dispcode_4 30001/4
 
AV:45
11-Error Code errcode_4 40001/4
 
AV:10
08-Unit Status unitstat_4 30002/4
 
AV:46
09-Ret Flow Temp returntemp_4 41004/4
 
AV:11
