AERCO XPC GATEWAY Communications - Manual (Page 125)

GF-122 AERCO XPC GATEWAY
125
Table 8 AERCO C-More & BMS/BMS II Point Definitions - Continued
Equip. Point Name
BAS Modbus
Data Addr
GF-108, GF-124,
GF-114 Point
Name
Reg.
Type
Modbus Data
Addr (Hex/Dec.) Units (Range)
Boiler Management System (BMS/BMS II)- Cont.
14-Boiler 5 Status 30022 Boiler 5 Status
(PWM Boiler 5) Input 0x0015 / 21 Enum (1 to 40, 119, 120)
1 to 40 = Fired and
Sequence
119 = Not On Line
120 = On Line But Not
Fired
15-Boiler 6 Status
30023 Boiler 6 Status
(PWM Boiler 6) Input 0x0016 / 22
Same As Above
16-Boiler 7 Status
30024 Boiler 7 Status
(PWM Boiler 7) Input 0x0017 / 23
Same As Above
17-Boiler 8 Status
30025 Boiler 8 Status
(PWM Boiler 8) Input 0x0018 / 24
Same As Above
18-Net Blr 1 Status 30026 Net Boiler 1 Input 0x0019 / 25 Enum (1 to 40, 119, 120)
1 to 40 = Fired and
Sequence
119 = Not On Line
120 = On Line But Not
Fired
121 = On Line But
Disabled
122 = On Line But Faulted
19-Net Blr 2 Status
30027 Net Boiler 2 Input 0x001A / 26
Same As Above
20-Net Blr 3 Status
30028 Net Boiler 3 Input 0x001B / 27
Same As Above
21-Net Blr 4 Status 30029 Net Boiler 4 Input 0x001C / 28 Same As Above
22-Net Blr 5 Status
30030 Net Boiler 5 Input 0x001D / 29
Same As Above
23-Net Blr 6 Status
30031 Net Boiler 6 Input 0x001E / 30
Same As Above
24-Net Blr 7 Status
30032 Net Boiler 7 Input 0x001F / 31
Same As Above
25-Net Blr 8 Status
30033 Net Boiler 8 Input 0x0020 / 32
Same As Above
26-Net Blr 9 Status
30034 Net Boiler 9 Input 0x0021 / 33
Same As Above
27-Net Blr 10 Status
30035 Net Boiler 10 Input 0x0022 / 34
Same As Above
28-Net Blr 11 Status
30036 Net Boiler 11 Input 0x0023 / 35
Same As Above
29-Net Blr 12 Status
30037 Net Boiler 12 Input 0x0024 / 36
Same As Above
