1.10.8 AERCO XPC to C-More
AERCO XPC TO C-MORE
XPC Part Number:
•
25024-1 or 63046-1 for 1 BMS and up to 4 C-MOREs; 25024-2 for 1 BMS and up to 12 C-MOREs; 25024-5 for 1
BMS and up to 8 C-MOREs
XPC Port 2 to C-MORE (I/O Box) RS485:
•
Wire to XPC Port 2  “Net+” to “RS485+”, “Net-” to “RS485-”, and Shield connected at one end only - to the C-
MORE (I/O Box) at the “SHLD” input.. Daisy chain to the other units..
•
Place 4-position jumper on EIA-485 (two bottom rows);
•
Place 2-position jumper on 2W;
XPC Software Setup:
•
Modbus Response Time = 2 (x100 msec); (Must be changed using AppLoader Software and Programmer Cable.)
C-MORE Setup:
•
For Monitor Only  “Comm Address” = (boiler address starting with “1”);
•
For Monitor and Remote Setpt Control via Modbus  Set “Comm Address” as above; Set “Boiler Mode” to
“Remote Setpt”; Set “Remote Signal” to “Network”.
BE SURE TO CYCLE AERCO XPC POWER AFTER MAKING ANY DIPSWITCH OR JUMPER CHANGES
AERCO XPC
C-MORE
Port 1a Port 2
RS485 RS485
m
odbu
s
