AERCO XPC GATEWAY Communications - Manual (Page 143)

GF-122 AERCO XPC GATEWAY
143
Modbus-To-BACnet Protocol Mapping
4 ECS Heaters
Equipment Point Name Name
Modbus Data
Addr/Unit
Addr
Read
Only Enabled
BACnet
Type:ID
E Valve Addr 29
01-Cntl Output Signal boilerstate_1
30004/29  
AV:11
02-Setpoint effectsetpt_1
30006/29  
AV:80
03-RmSetpt rmsetpt_1
40027/29 
AV:81
04-Outlet Temp localsuptemp_1
30002/29  
AV:84
05-FBk Sensor Temp localrettemp_1
30290/29  
AV:1
06-Over Temp Alarm unitstat_1
30075/29  
AV:86
07-Flow Rate flowrate_1
30291/29  
AV:2
Use Metric Conversion m101_1

BV:17
E Valve Addr 30
01-Cntl Output Signal boilerstate_2
30004/30  
AV:12
02-Setpoint effectsetpt_2
30006/30  
AV:3
03-RmSetpt rmsetpt_2
40027/30 
AV:4
04-Outlet Temp localsuptemp_2
30002/30  
AV:5
05-FBk Sensor Temp localrettemp_2
30290/30  
AV:6
06-Over Temp Alarm unitstat_2
30075/30  
AV:7
07-Flow Rate flowrate_2
30291/30  
AV:8
Use Metric Conversion m101_2

BV:3
E Valve Addr 31
01-Cntl Output Signal boilerstate_3
30004/31  
AV:9
02-Setpoint effectsetpt_3
30006/31  
AV:150
03-RmSetpt rmsetpt_3
40027/31 
AV:151
04-Outlet Temp localsuptemp_3
30002/31  
AV:152
05-FBk Sensor Temp localrettemp_3
30290/31  
AV:153
06-Over Temp Alarm unitstat_3
30075/31  
AV:154
07-Flow Rate flowrate_3
30291/31  
AV:155
Use Metric Conversion m101_3

BV:27
E Valve Addr 32
01-Cntl Output Signal boilerstate_4
30004/32  
AV:10
02-Setpoint effectsetpt_4
30006/32  
AV:158
03-RmSetpt rmsetpt_4
40027/32 
AV:159
04-Outlet Temp localsuptemp_4
30002/32  
AV:160
05-FBk Sensor Temp localrettemp_4
30290/32  
AV:161
06-Over Temp Alarm unitstat_4
30075/32  
AV:156
07-Flow Rate flowrate_4
30291/32  
AV:157
Use Metric Conversion m101_4

BV:29
