AERCO XPC GATEWAY Communications - Manual (Page 167)

GF-122 AERCO XPC GATEWAY
167
Modbus-To-LonWorks Protocol Mapping 1 BMS/BMS II, 8 C-More Boilers (Continued)
Equipment Point Name Name
Modbus Data
Addr/Unit Addr
Read
Only Enabled
SNVT
# SNVT NAME SNVT
Element
# Direction Prio Auth Ack
BMS Addr 128
01-Fire Rate Out boilerstate_13 30005/128
 
1 nvoBlrState
incremental
count (9)
0
Output (non-
polled)
02-Header Set
Temp
effectsetpt_13 30006/128
 
2 nvoEffSetpt
incremental
count (9)
0
Output (non-
polled)
03-Net Header Set
Temp
setpt_13 40005/128

3 nviSetpt
incremental
count (9)
0
Input (non-
polling)
04-Header Temp localsuptemp_13 30002/128
 
4 nvoLocSupTmp
incremental
count (9)
0
Output (non-
polled)
05-Outside Air
Temp
localoatemp_13 30003/128
 
5 nvoLocOATmp
incremental
count (9)
0
Output (non-
polled)
06-Display Code dispcode_13 30011/128
 
6 nvoDispCode
incremental
count (9)
0
Output (non-
polled)
07-Num Boilers
Fired
blrfired_13 30008/128
 
7 nvoBlrsFired
incremental
count (9)
0
Output (non-
polled)
08-Num Boilers
Online
blronline_13 30009/128
 
8 nvoBlrsOnline
incremental
count (9)
0
Output (non-
polled)
09-Last Blr Fired blrlast_13 30017/128
 
9 nvoLastBlrFired
incremental
count (9)
0
Output (non-
polled)
10-Boiler 1 Status blr1stat_13 30018/128
 
21 nvoBlr1Stat
incremental
count (9)
0
Output (non-
polled)
11-Boiler 2 Status blr2stat_13 30019/128
 
22 nvoBlr2Stat
incremental
count (9)
0
Output (non-
polled)
12-Boiler 3 Status blr3stat_13 30020/128
 
23 nvoBlr3Stat
incremental
count (9)
0
Output (non-
polled)
13-Boiler 4 Status blr4stat_13 30021/128
 
24 nvoBlr4Stat
incremental
count (9)
0
Output (non-
polled)
14-Boiler 5 Status blr5stat_13 30022/128
 
25 nvoBlr5Stat
incremental
count (9)
0
Output (non-
polled)
15-Boiler 6 Status blr6stat_13 30023/128
 
26 nvoBlr6Stat
incremental
count (9)
0
Output (non-
polled)
16-Boiler 7 Status blr7stat_13 30024/128
 
27 nvoBlr7Stat
incremental
count (9)
0
Output (non-
polled)
17-Boiler 8 Status blr8stat_13 30025/128
 
28 nvoBlr8Stat
incremental
count (9)
0
Output (non-
polled)
18-Net Blr 1 Status blr9stat_13 30026/128
 
29 nvoNetBlr1Stat
incremental
count (9)
0
Output (non-
polled)
19-Net Blr 2 Status blr10stat_13 30027/128
 
30 nvoNetBlr2Stat
incremental
count (9)
0
Output (non-
polled)
20-Net Blr 3 Status blr11stat_13 30028/128
 
31 nvoNetBlr3Stat
incremental
count (9)
0
Output (non-
polled)
21-Net Blr 4 Status blr12stat_13 30029/128
 
32 nvoNetBlr4Stat
incremental
count (9)
0
Output (non-
polled)
Page 6 of 7
